Name: Bottle Shape Bag Pure Water Mineral Water Filling Machine Sealing Machine
Brand: LANGHUI
Price: 1 USD

Ask Lasest Price
Brand Name :	LANGHUI
Model Number :	BD1410A
Price :	Negotiable
Delivery Time :	20 days from the date we received your samples and deposit.
Payment Terms :	T/T with 50% deposit and 50% balanced before shipment.
Supply Ability :	60 Per Month

Add to Cart

BD1410A 360° ALL VIEW

The stick pouch is a popular international plastic bag. It is also called Expansion Bags | Plastic Bag | Stand Up Pouch | Pre-Shaped Bag | Spout Pouch | Formed Bag | Bottle Shape Pouch | Fruit Shape Pouch | Fruit Shape Bag | Various Shape bag | Sachet | Doypack. It is a novel form of packaging, diverse modeling, reliable measurement, seal firm, easy to use, and low cost packaging materials, etc.
It is widely used in dairy products such as Pure Water | Mineral Water | Soda Water | Coconut Water | Carbonated Beverage, etc.

It adopts 304 stainless steel, and PLC system control.
Chinese and English man-machine visualization operation interface. It is automatic entire process by PLC control system, such as filling, sealing, dropping bags, etc.
It adopts airless pressurized filling. It can effectively avoid secondary pollution. The filling volume is adjustable.
Unique sealing part design, seal suitable location and firm.It add Teflon material in the sealed parts when you want to seal PE or Nylon pouch.
Comprehensive safety design, with earth-leakage protection.
Each features a modular, easy maintenance.
Unique filling nozzles and anti-drip valve design, no leaking filling and save cost.

Model	BD1410	BD1410A	BD1410B
Packing rate	2000-3500 bags/hr	2000-3500 bags/hr	2000-3500 bags/hr
Filling nozzles	8	8	8
Workstation	2	2	2
Bag material	PE or Nylon, BOPP laminated LDPE, various shapes pre-shaped bags
Film thickness	＞0.18mm	＞0.18mm	＞0.18mm
Filling volume	≤500ml (Custom)	≤500ml (Custom)	≤500ml (Custom)
Filling accuracy	≤±2%	≤±2%	≤±1%
Power input	220V / 110V 50Hz	220V / 110V 50Hz	220V / 110V 50Hz
Power	0.8-1.6 Kw	0.8-1.6 Kw	0.8-1.6 Kw
Air Pressure	0.6-0.8 Mpa	0.6-0.8 Mpa	0.6-0.8 Mpa
Air Consumption	0.25-0.50 m³/min	0.25-0.50 m³/min	0.50-0.75 m³/min
Net weight	≈80 kg	≈80 kg	≈120 kg
Overall dimension	1100×700×1050mm³(LWH)	1100×700×1050mm³(LWH)	1100×700×1050mm³(LWH)
Gross weight	≈120 kg	≈120 kg	≈240 kg
Packaging dimension	1300×850×1250mm³(LWH)	1300×850×1250mm³(LWH)	1300×850×1250mm³(LWH)
